Dometic RTX 2000 Air Conditioner - 2000W, 12V - 9600028490

Blog Post:

Dometic RTX vs Nomadic Cooling



RackUp+Go is North America's #1 Dometic RTX Dealer

Best Price & Service Guaranteed!



Typically Ships Same or Next Business Day

  • Same-Day Pick Up Available @ Our Sioux Falls, SD Warehouse



MAXIMUM COOLING, MINIMUM ENERGY


The third generation CoolAir from Dometic includes an entirely new technology. The ingenious Dometic CoolAir RTX 2000 provides added cooling performance and runtime compared to other units - without consuming more energy! The variable speed inverter compressor allows for best-in-class cooling while operating both quietly and efficiently.

This unit is self-contained, meaning you do not need a thermostat or any additional components to operate this 12V battery powered unit. It is unbelievably efficient with only 19A consumption in Eco mode. Power consumption in other modes ranges between 10 amps to 58 amps.



  • 6,824 BTU, 12 Volt - (Dometic advertises lab-tested performance of the RTX unit. Most competitor brands only advertise "Rated" BTU.)
  • INTEGRATION INTO ROOF
  • VARIABLE SPEED CONVERTER COMPRESSOR
  • 180Ah+ BATTERY BANK RECOMMENDED
  • BEFORE ORDERING, PLEASE REVIEW INSTALLATION MANUAL
    • Professional installation recommended. Installation error can cause damage or injury. A professional installer is able to adhere to fitment and electrical wiring standards in your area. If you are not confident in personally installing this unit, please contact a trusted local technician for support.


Warranty:

Limited 1 Year Warranty Included

*The unit by itself only comes with a pigtail wire connector. If you order the RTX unit by itself, (without the above listed Installation Kit) your order will arrive with NO installation hardware or wiring.

**Per Dometic, failure to properly install using Dometic approved installation kit may void the warranty.

Not Included:

  • Batteries
  • RV Roof Sealant

Freight

This product ships LTL Freight. For residential deliveries, the customer will need to be available by phone for the carrier to schedule delivery. Prompt scheduling is required.


EFFICIENCY THAT WORKS FOR CAMPER VANS & TRUCK CABS

A familiar picture for offgrid campervans and truck parking areas: drivers leaving the engine running for hours to use the air conditioner or to recharge the batteries during their resting periods. Not only is this terrible for the environment, it’s also against the law in most areas. Tons of fuel wasted, and operators pay dearly for it. Plus, it accelerates engine wear. The Dometic RTX  keeps operating costs down. Equally important to is the fact that it improves safety and thus ensures that operators remain safe and sound. The Dometic CoolAir RTX is a powerful self-contained air conditioner.


...AND MORE

    • 2000W (6,824 BTU), 12 Volt - (Dometic advertises actual performance. Most competitors advertise their unit's "Rated" BTU.)
    • Up to 12 hours of running time
    • Very quiet
    • Suitable for ambient temperatures of 41 °F to 126 °F
    • Turbo cooling operating mode for quick cooling
    • All A/C components integrated into the unit
    • Highly efficient: only 19A in Eco mode. Power consumption in other modes ranges between 10 amps to 58 amps.



HIGHER EFFICIENCY AND MORE POWER

The Dometic CoolAir RTX comes with an entirely new technology to continue a unique success story. CoolAir compressor parking coolers have been around for over ten years to improve working conditions, safety and cost efficiency in the European utility vehicle industry. The third generation Dometic CoolAir roof air conditioners do that in two convincing ways: it provides more cooling performance and a longer running time while consuming less energy than its predecessor model. The RTX 2000 generates more than twice the cooling power of the RTX 1000, but at the same running time. All of this is possible thanks to the use of a variable speed inverter compressor, which makes for excellent cooling performance and amazingly efficient and quiet operation.


QUALITY FEATURES

The Dometic Coolair RTX 1000 creates pleasant temperatures for up to twelve hours before the battery monitor gives advance warning and finally cuts off the power supply to keep the engine ready to start. The even more powerful RTX 2000 uses its ample capacity to face hot temperatures in the truck cabin for up to twelve hours. Added to this, the CoolAir RTX is amazingly quiet in operation. The two-cylinder compressor works unnoticeably, leaving the driver to rest perfectly to enjoy all the comforts of their cabin: the large, high-contrast display, the individually adjustable air distribution, the four operating modes – and the adaptive automatic mode of the air conditioner. Drivers are fascinated by the enormous staying power of the CoolAir RTX.

SPECIFICATIONS

GENERAL

  • SKU number 9600028490
  • Model RTX2000
  • Model on label RTX2000
  • Cool Only or Heat Pump Cool Only
  • CertificationNot NRTL Tested
  • Product Description Truck Air Conditioner, 2000W (6,824 BTU), 12 V
  • Thermostat Zones Single




DIMENSIONS

Dometic CoolAir RTX Dimensions

  • Dimensions full product depth 25.39 "
  • Dimensions full product height 12.13 "
  • Dimensions full product width 33.86 "
  • External dimensions height 6.6 "
  • External dimensions length 25.4 "
  • External dimensions width 33.9 "
  • Internal dimensions height 5 "
  • Internal dimensions length 15 "
  • Internal dimensions width 14 "
    • A 18.9 in. x 15.3 in. (480 mm x 390 mm) opening is required.
  • Net weight 70.56 lbs

ELECTRICAL

  • Input voltage (DC) 12 V

PERFORMANCE

  • Cooling capacity (ISO 5151) 2000 W
  • Cooling Capacity 6824  BTU (Dometic advertises actual lab-tested performance of the RTX. Most competitor brands only advertise their unit's "Rated" BTU.)

Unit Placement Requirements

  • A 18.9 in. x 15.3 in. (480 mm x 390 mm) opening is required. The roof opening is part of the return air system of the unit.
  • The joist support frames must be spaced no greater than 16 in. (406 mm) on center. The unit is designed to fit over an existing roof vent opening or a new roof opening created by the installer.
  • When no roof vent is available or when another location is desired, an opening must be cut through the roof and ceiling of the vehicle. This opening must be located between the roof reinforcement beams.
  • Mount the unit slightly forward of the vehicles center (front to back) and centered from side to side.
  • The ventilation openings must not be covered. A minimum distance of 3.8 in. (98 mm) must be maintained from other external attachments.



Customer Testimonials:






Warranty:



Limited 1 Year Warranty

*The unit by itself only comes with a pigtail wire connector. If you order the RTX unit by itself, (without the above listed Installation Kit) your order will arrive with NO installation hardware or wiring.

**Per Dometic, failure to properly install using Dometic approved installation kit may void the warranty.
