12V 200Ah LiFePO4 Deep Cycle Lithium Battery

ACOPOWER 12.8V 200Ah LiFePO4 Battery (200A BMS)

The ACOPOWER 12.8V 200Ah LiFePO4 battery delivers reliable power for off-grid solar systems, RV power storage, marine applications, and backup energy storage. With an advanced 200A BMS and over 4000 life cycles, this battery provides long-term performance and high safety.

Key Features

• High Capacity Energy Storage – 12.8V 200Ah battery providing up to 2560Wh energy.
• Built-in 200A BMS Protection – Protects against over-charge, over-discharge, and short circuit.
• Long Cycle Life – More than 4000 charge cycles for long-term solar energy storage.
• High Power Output – Supports up to 200A continuous discharge current.
• Lightweight LiFePO4 Technology – Safer and lighter compared with traditional lead-acid batteries.

Applications

• Solar energy storage systems
• RV & camper power systems
• Marine / boat electrical systems
• Off-grid cabins
• Backup power storage

Specifications

Battery Dimensions

• Length: 21 in (532 mm)
• Width: 8.2 in (207 mm)
• Height: 8.5 in (215 mm)

Operating Temperature

• Charge: 0°C – 50°C (32°F – 122°F)
• Discharge: -20°C – 60°C (-4°F – 140°F)
• Storage: -10°C – 50°C (14°F – 122°F)

Expandable Battery System

The battery supports series and parallel connections for higher voltage or larger capacity systems. Up to 4 batteries can be connected in series (48V system) or multiple units in parallel for increased capacity.

Safety Protection

• Over-charge protection
• Over-discharge protection
• Short-circuit protection
• Over-current protection
• Temperature protection

User Manual

⏬200Ah User Manual
